To end #HenkelWeek24, we are highlighting our #HenkelBestSeller – Ablestik 45W1/Catalyst 15 (Twin Pack)!
LOCTITE ABLESTIK 45 W1 is designed as a general purpose, adhesive and is particularly useful when bonding dissimilar substrates such as metal to plastic. It is designed for use where shock and peel resistance are desired. This product is recommended to be used with Catalyst 15.
Introducing Bergquist Gap Pad TGP 40000SF and Bergquist Gap Pad TGP 18000SF, the two newest silicone free gap pads from Henkel. These fantastic thermally conductive fillers excel with heat transfer thanks to their z-axis orientation which allows for heat to transfer effectively from component to heat spreader.
Due to the no-cure system these products have, it makes it simple to pick and place them allowing for them to be reworkable. On top of this, due to their non-silicone polymer binder there is very low amount of bleed/ outgas from these Gap Pads. With their elastomeric properties, both the 40000SF and 18000SF have a high temp reliability for a non-silicone gap pad.
Bergquist Gap Pad 18000SF being applied
The differences in properties
40000SF
40 W/mK
0.39 K-cm2/W @ 20psifor 0.5mm pads
Not electrically insulating
Carbon-based fillers in elastomer matrix
18000SF
18 W/mK
0.67 K-cm2/W @20psifor 0.5mm pads
Electrically Insulating
Ceramic based fillers in elastomer matrix
Applications
Typical applications include:
5g Telecoms – servers, switches, routers
Automotive ADAS – vehicle control units, radar sensors and power modules
HDDs, CPUs, GPUs and ASICs in high end computing and gaming
Aerospace and Defence – embedded processors and satellite payloads
High thermal performance requirements
Optical transceivers, lasers and Satellite payloads
Thicker bondline requirements.
Where disassembly may occur
No post-processing is preferred – power modules using solders requiring reflow
Immersion cooling applications in datacentres
Bergquist Gap Pad 40000SF being applied
For a more in depth look at these two new products visit their specific product pages where you can enquire about them!
For the last #ProductSpotlight of #HenkelWeek24 we are focusing on BERGQUIST GAP PAD TGP 2400!
BERGQUIST GAP PAD TGP 2400 is a thermally conductive gap pad reinforced for easy handling and versatility. Providing a conductivity of 2.4 W/m-K, it efficiently transfers heat away from electronic components. The soft, elastic material conforms well to uneven surfaces, ensuring optimal thermal performance. This reinforced pad offers improved tear resistance, electrical isolation, and easier conversion for various applications. Well-suited for low-pressure applications, GAP PAD TGP 2400 comes with natural tack on both sides for simple assembly. Alternatively, a non-tack version is available for specific needs.
• Thermal Conductivity: 2.0 W/m-K • Low S-Class thermal resistance at very low pressures • Highly Conformable, low hardness • Designed for low-stress applications • Fiberglass reinforced for puncture, shear and tear resistance • Part Number – GP2500S20-0.160-02-0816
Our second #ProductSpotlight of #HenkelWeek24 is Ablestik 45 Clear/Catalyst 15 Clear (Twin Pack)
LOCTITE ABLESTIK 45 CLEAR is an unfilled epoxy adhesive which, by using catalyst 15 clear, can adjust the hardness from flexible to rigid. It has an easy mix ratio and bonds well to a wide variety of substrates. LOCTITE ABLESTIK 45 CLEAR is an unfilled, clear version of ABLESTIK 45
For the first #ProductSpotlight of #HenkelWeek2024 we are focusing on a thermally conductive encapsulant Stycast 2850FT!
Stycast 2850FT is a powerful encapsulation solution for thermally sensitive electronic components. Its exceptional thermal conductivity, superior shock resistance, and low CTE make it a top choice for ensuring optimal performance and longevity in various demanding applications.
Features and Benefits:
• General Purpose • Low Viscosity • Cures at Room Temperature • Good Machinability • Reduced Abrasion • Good Chemical Resistance
As mentioned on Friday we are kicking of #HenkelWeek2024 by putting a spotlight on their brand. From Adhesives and Encapsulants to their incredible Thermal range we always have a wide array of products available.
Take a look at some of their exciting categories below:
Electrically Conductive Adhesives – This is products such as Ablestik 60L, Ablestik 59c, Ablestik 56c and Ablestik 64c
Thermal Insulating Pads – This is products such as BERGQUIST GAP PAD TGP 1350, BERGQUIST GAP PAD TGP 1500R, BERGQUIST SIL PAD TSP 1600 and BERGQUIST SIL PAD TSP 1800ST
Thermally Conductive Encapsulants – This is products such as Stycast 2850MT, Stycast 2851FT, Stycast 2850FT & Catalyst 9 (1kg) and Stycast 2850FT
