BERGQUIST HI FLOW THF 1500P

SKU: BG1030

Product Description

BERGQUIST HI FLOW THF 1500P offers a unique combination of thermal conductivity and electrical isolation. This phase change material efficiently transfers heat away from electronic components. A reinforced polyimide film provides excellent cut-through resistance, high dielectric strength, and ideal high-temperature performance for automotive applications.

Designed for devices requiring electrical separation from heat sinks, BERGQUIST HI FLOW THF 1500P is perfect for automated dispensing systems. For optimal thermal performance, Henkel recommends using spring clips to maintain constant pressure between the component and the heat sink. Refer to the TO-220 thermal performance data sheet (available separately) to determine the appropriate spring pressure for your specific application.

  • Thermal impedance: 0.2C-in2/W @ 25 psi
  • 150C high temperature reliability
  • Natural tack one side for ease of assembly
  • Exceptional thermal performance in an insulated pad
  • Dimensions – 304mm x 279.4mm x 0.127mm
  • Part Number: HF650P1.0-0.0045-01-1112

Additional Info

Weight

0.244 kg

Weight 0.244 kg
Part Number

THF 1500P (304mm x 279.4mm x 0.127mm)

Reviews

Reviews

There are no reviews yet.

Be the first to review “BERGQUIST HI FLOW THF 1500P”

£51.22 ex VAT

In stock (can be backordered)

x
Add to RFQ Basket
